WE SERVICED 1950's & 1960's DELCO WONDER BAR and TRANSPORTABLE RADIOS 1966 thru 2014



WELCOME TO TOM'S ANTIQUE DELCO CAR RADIO SERVICE WEB PAGE. PROFESSIONAL DELCO CAR RADIO REPAIRS since 1966. United Motors Service trained for Delco Radios and 50 Years of experience servicing DELCO and UNITED MOTORS SERVICE car radios for GM automobiles. These also include PACKARD, STUDEBAKER and some CHRYSLER PRODUCTS RADIOS (made by Delco). We are Delco Wonder Bar & Transportable specalists. We are RETIRED from service and restoration projects. Service Manuals and lookup service will still be avaliable.

We have most service manuals for DELCO CAR RADIOS (Buick..Cadillac..Chevrolet..Oldsmobile..Pontiac and other Delco Radio Products), CADILLAC MOTOR CAR RADIOS AND UNITED MOTORS CAR RADIOS between the years 1930 and 1994. We will need the THE YEAR AND MAKE OF THE CAR, MODEL NUMBER, PART NUMBER, SERVICE REFERENCE NUMBER and BULLETIN NUMBER. They will be on the same label as the model number. This number is inside the top cover of older radios on an orange label. In later years, the part number is on the outside of the radio. You may not find all the number but send me the ALL the numbers you have. A PICTURE OF THE LABEL WOULD BE GREAT!

We sell duplicate paper service manuals if avaliable. We will also scan & deliver service manuals in electronic PDF form. Click the email icon below and ask for the manual you need and We will let you know how many pages in the manual. Most manuals from 1930 to 1969 are under 10 pages. 1970 to 1993 are large manuals because of the complexity of the radio receivers. Then you can then select the appropriate drop down and then click the BUY NOW button. We will scan it and let you know when it is ready and then deliver it via by email or Hightail.....WE NOW HAVE DELCO PDF SERVICE INSTRUCTION MANUALS FOR THE WONDER BAR MECHANICS. These are NOT included in the car radio service manuals. They are training and trouble shooting manuals. The F1 & F2 manuals are for Corvette Wonder Bar Radios. See drop down below.

Ask us about Delco & United Motors Service Manuals

CLICK HERE
Ask us about PDF Delco and United Motors Service Manuals

SELECT ITEM FROM DROP DOWN AND THEN CLICK BUY NOW

PDF & PAPER SERVICE MANUAL PRICES

ALL PDF SERVICE MANUALS WILL BE SENT VIA HIGHTAIL FOR DOWNLOAD OR BY EMAIL. A LINK WILL BE SENT BY EMAIL AND WILL BE GOOD FOR 3 DAYS.

Download a free copy of the Adobe ReaderĀ® to read the PDF.


Click Here

CUSTOMER COURTESY SERVICE--We can provide you FREE with the YEAR and MODEL CAR your DELCO CAR RADIO, CADILLAC MOTOR CAR RADIO AND UNITED MOTORS CAR RADIO belongs to between the years 1930 and 1993 if you can if you can supply the MODEL NUMBER of the radio. This number is inside the top cover of older radios on an orange label. In later years, the part number is on the outside. I also need the SERVICE REFERENCE NUMBER and BULLETIN NUMBER that will be on the same label as the part number. A PICTURE of the RADIO WOULD be GREAT!

Send us your Model Number and find out the make and year car your Delco Radio belongs to for FREE!!

CLICK HERE
Ask us about Delco Wonderbar and Transportable Radio Repairs





1958 OLDSMOBILE TRANSPORTABLE RADIO




1962 CHEVROLET CORVETTE WONDER BAR RADIO




1935 BUICK RADIO VIBRATOR


DELCO ELECTRONICS 60 YEAR HISTORY
